Faulty refrigerator Atlant.

Faulty refrigerator Atlant.

  1. Remove relay starting (on the compressor a plastic box). E then easily put back, do not confuse. Remove from the no cover and put the relay back BUT without the cover and turn it on. If the spiral on the relay is heated to red and turns off the compressor and it is hot, then the winding of the starting khan in the compressor (there they are 2). Only a dump will save him. If the relay crumbles or cracks inside and smells, then it means that the relay is out of order (sold). But from my experience I will say that if the refrigerator is trying to work and almost immediately turns off, then in percentage 95-ty pipets came to the compressor itself. Well, the extreme case - someone unsuccessfully chipped the ice in the freezer with a knife and broke through the frost. camera and freon came out
  2. If the refrigerator turns on and then goes off soon, there is a shutdown at all, then the refrigerator turns off something.
    About a particular model I do not know. I'll write it for a simple case.
    Disconnect the refrigerator can only two devices.
    Normally it turns off the thermostat.
    Accidentally it is switched off by a relay relay.
    The thermostat normally stands inside the refrigerator, and the temperature adjustment knob just sticks out of it. From the thermostat there is a tube of a thermosensor to the evaporator, the one that is cold inside.
    A start-up relay usually stands behind the motor and represents two different devices located in the same housing. The starting relay provides start of the motor. A safety relay protects the motor from combustion.
    Quickly turn off the refrigerator theoretically can both relays - thermal and protective.
    The thermo relay can quickly operate if from its tube through a crack it is strong duck cold - there too a freon, as well as in the refrigerator, in any way with hladonom in the refrigerator not connected. is used for temperature sensitivity.
    The safety relay can quickly switch off the refrigerator if the spring is loosened in this relay. Or if the motor is shorted, and the protection is triggered in the usual way.
    If the trip occurs after a few seconds - more like a protective relay. If more than twenty seconds - more like a thermostat.
    It is difficult to determine without diagnosis and verification on the spot.
    There is a scrap method to ensure the operation of the refrigerator, if it is a relay. For example, it is possible, but very dangerous, to turn on the compressor motor directly, without a thermal relay and protective relay. Then the refrigerator will just work without stopping, if it was a relay. In this case it is necessary to switch on via the start relay, if there is no experience to start manually, there the circuit at start-up and after a few seconds is fundamentally different, the wrong one usually burns the motor. But when connected directly, without a protective relay, in the event of a short circuit, the motor may burn, there is nothing to disconnect it. This can lead to a fire.
  3. And where is Atlant something? In the photo, anything, but not him.
